标准 Standard | 牌号 Alloy Code | 状态 Temper | 抗拉强度(Mpa) Tensile Strength | 屈服强度(Mpa) Yielld Strength | 延伸率 (%) Elongation | 扩口(%) Expansion Requiremen | 维氏硬度 (HV5) Hardness | 晶粒度 (mm) Grain Size |
Min | Min | Max | Min | Min | Min | Max | Min | Max |
BS 2871 | CN107 | M | - | - | - | - | 25 | 150 | - | - | - |
O | - | - | - | - | 25 |
| 120 | - | - |
CN108 | M | - | - | - | - | 25 | 150 | - | - | - |
O | - | - | - | - | 25 | 90 | 120 | - | - |
CZ110 | M | - | - | - | - | 25 | 150 | - | - | - |
TA | - | - | - | - | 25 | 85 | 110 | - | 0.05 |
O | - | - | - | - | 25 | - | 75 | - | - |
CZ111 | M | - | - | - | - | 25 | 150 | - | - | - |
TA | - | - | - | - | 25 | 80 | 150 | - | 0.05 |
O | - | - | - | - | 25 | - | 75 | - | - |
EN 12451 | CuNi 10Fe 1Mn | R290 | 290 | 90 | - | 30 | 30 | - | - | - | - |
R310 | 310 | 220 | - | 12 | 20 | - | - | - | - |
R480 | 480 | 400 | - | 8 | 8 | - | - | - | - |
CuNi30 Mn 1Fe | R3700 | 370 | 120 | - | 35 | 30 | - | - | - | - |
R480 | 480 | 300 | - | 12 | 20 | - | - | - | - |
CUZn20AL2As | R340 | 340 | 120 | - | 55 | 30 | - | - | - | - |
R390 | 390 | 150 | - | 45 | 30 | - | - | - | - |
CuZn28Sn1As | R320 | 320 | 100 | - | 55 | 30 | - | - | - | - |
R360 | 360 | 140 | - | 45 | 30 | - | - | - | - |
CuZn30As | R340 | 340 | 130 | - | 45 | 30 | - | - | - | - |
JIS H33 | C70 | O | 275 | - | - | 30 | 25 | - | - | 0.01 | 0.045 |
C7150 | O | 365 | - | - | 30 | 25 | - | - | 0.01 | 0.045 |
C7164 | O | 430 | - | - | 30 | 25 | - | - | 0.01 | 0.045 |
C6870 | O | 375 | - | - | 40 | 25 | - | - | 0.01 | 0.045 |
C4430 | O | 315 | - | - | 30 | 25 | - | - | 0.01 | 0.045 |
铜合金管产品系列
牌号对照 Material Brand
材料名称 Materia I Designation | 相应牌号 Corresponding Material Symbol |
GB/T 8890 | ASTM B111 | BS2871 | JIS H3300 | DIN 1785 |
自 铜 Copper-Nickel | BFe10-1-1 | C70600 | CN102 | C7060 | CuNi10Fe1Mn |
BFe30-1-1 | C71500 | CN107 | C7150 | CuNi30Mn1Fe |
(BFe30-2-2) | C71640 | CN108 | C71 64 | CuNi30Fe2 Mn2 |
(BFe5-1.5-0.5) | C70400 | . | - | - |
B7 | - | - | - | . |
铝黄铜 Aluminium Brass | HAL77-2 | C68700 | CZ110 | C6870 | CuZn20AL2 |
锡黄铜 Admiralty Brass | HSn70-1 | C44300 | CZ1丁 1 | C4430 | CuZn28Sn1 |
加棚黄铜 Boric Brass | HSn70-1B |
|
| . | ' |
HSn70-1 AB | . | - | ' | . |
加砷黄铜 Arsenical Brass | H68A | - | CZ126 | - | - |
黄铜 BRASS TUBE | H65 / H63 | C28000/C27200 | CZ108 | C2800/C2700 | CuZn36/CuZn37 |
规格尺寸范围 Spec. dimension Range
外径OD （MM） | 壁厚WT(MM) |
0.5~1.0 | 1.0~1.5 | 1.5~2.5 | 2.5~4.0 | 4.0~6.0 | 6.0~10 | 10~15 |
＞5~10 | ○ | ○ | ○ |
|
|
|
|
＞10~16 | ○ | ○ | ○ | ○ |
|
|
|
＞16~25 | ○ | ○ | ○ | ○ |
|
|
|
＞25~35 | ○ | ○ | ○ | ○ | ○ |
|
|
＞35~50 | ○ | ○ | ○ | ○ | ○ | ○ | ○ |
＞50~65 |
| ○ | ○ | ○ | ○ | ○ | ○ |
＞65~80 |
|
| ○ | ○ | ○ | ○ | ○ |
长度(Lenth) | 最长25M（From0.5M~25M） |
执行标准(Standard) | GB/T8890 ASTMB111 BS2871 EN12451 JIS H3300 |
备注 :记号 表示本公司常规产品规格尺寸， 客户如有特殊要求 可按订单生 产。
Remaks:Ostands for the regular spec，dimensions.lf particular needs required，we can produce as per customer specification.
